Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



Features

• 1.8”(4.6cm),nine‐digitLED–availableinred,green,amberorblue

• AutomaticallydetectsandsyncstoIRIG‐BorSMPTE,

EBUnon‐dropframeTimeCodes

• ThreedigitDayofYeardisplay

• Six‐digittimedisplayin12‐or24‐hourformat–hh:mm:ss

• AllinternationalTimeZonesandautomaticDaylightSavingTimes

• Standardchassiscolorisblackpowdercoat

• WorldwideACPower

• Count‐downorcount‐uptimemodes

• CEmarkedforsaleinEU–FCC,ClassB,Emissions



SPECIFICATIONS

• ConfigureclocksthroughUSBserialinterface

• ConfigurationutilityrunningunderMicrosoftWindows

• World‐wideTimeZoneandDSTappconfiguration

• Commandlineinterface(anddrivers)forusewithLinux,

Unix,MAC

• Up/downtimermodecontrolledwithRC500orUSB

serialport

• Configurationissavedtonon‐volatilememoryto

survivepowerloss





Physical

Size:

17.5wx3.75hx3.0din

Weight:

3.2lbs

44.5wx9.6hx7.6dcm 1.4kg



OperatingParameters

• Temperature:0to+40°C

• Humidity:Upto90%(non‐condensingat+25°C)



Connectors

• BNCfemale:UnbalancedTCinput

• Terminalblock:3position,balancedTCinput

• USBconnector:forsetup

• 2.1mmmalelockingDCinputjack(DCoption)

• IECconnector(ACoption)



Power

• Powerconsumption:<13W

• ACoption:International115/230,50/60Hzsupplied

withchoiceofUS,Euro,BritishorAUS/NZpowercord

–othersavailable

• DCoption:

o VDCinputcanbeusedasbackuporprimarypower

o IncludesexternalACtoDCwall‐mountpower

supplywithlockingDCplug

o SuppliedwithchoiceofwalltransformerUS,Euro,

BritishorAUS/NZplug–othersavailable

Time Code Driven Cloc

TCDS 29

MOUNTING BRACKETS

RackMount

Bracketfor

19”2URack

‐or‐

WallMount

Bracket

TiltWall

Bracket

Option
