Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



FEATURES

• GeneratessignalsforNENA/PSAPequipment

• OperatefromIRIG‐BorSMPTETimeCodeinputs

• IRIG‐Bmodulatedorpulse‐widthencodedTimeCodeoutput

• IRIG‐Emodulatedorpulse‐widthencodedTimeCodeoutput

• AllTimeCodeoutputssupportsignaturecontrol

• AllTimeCodeoutputsencodeNENAextensions

• SupportsNENA‐definedASCIIoutputsat

9600,4800,2400,and1200baud

• PerformTimeZoneadjustmentsin

display,serial,andTimeCodeoutputs

• PerformDaylightSavingsTimeadjustmentin

display,serial,andTimeCodeoutputs

• ProvidesdrycontactclosurealarmforTimeCodeorpowerloss



SPECIFICATIONS

I/OConnections

• Inputpower:12‐28VDC

• 2.1mmmaleDCpowerconnector

• TimeCodeinput:BNCsocket

• RS‐232,pulse,contactclosureandTimeCodeoutput‐

DB‐9male

• OptionalDB‐9toBNCadapterBNC‐9





OperatingParameters

• Temperature:0to+70°C

• Humidity:Upto90%,non‐condensing





Physical

Size:

4.2wx1.5tx5.5din

Weight:

16oz

10.6wx3.8tx14dcm 435g

   

Case

• Cover:off‐whitealuminum

• Front/rearpanel:clearanodizedaluminum

• Optionalrackmountkitavailable:RM4



Time Code Interfac

TCI NENA

Rack mountable with an RM4
