Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:sales

masterclock.com

online:www.masterclock.com



FEATURES

• AcceptsTimeCodeformats:SMPTE24‐fps(Film),25‐fps(EBU),30‐fpsNDF(Non‐DropFrame),

IRIG‐B0(unmodulated/pulsewidthmo dulated)andIRIG‐B1(amplitudemodulated,1kHz)

• Allowsmillisecondsynchronizationaccuracy

• AutomaticDaylightSavingsTimeanddate

• TCRSync1000softwarethatrunsasaserviceprovidingadditionaldiagnosticsandotherbenefits

underWindowsXP/7/Server2003and2008‐SP1

• Optionalsoftware–TCRSync‐NTPprovidesNTPreferenceforheterogeneousoperatingsystems

onanEthernetLAN

• APIsoftwaredevelopmentkitanddocumentationisprovidedfordesigners

SPECIFICATIONS



Connector

• BNCconnectorforTimeCodeinput

• Optionalthreepinpositivelocking,rightanglepin 

header(0.1"pinspacing)forTimeCodeinput

Physical

• Half‐heightcard

• Length:6.6"(167.6mm)

• Height:2.5"(63.6mm)



Otherfeatures

• LEDstatusindicator

• Universal32‐bit/33MHzor64‐bitbus

• 3.3Vand5Vuniversalcard

• Operatesinhigherspeedandwiderbuses

• DetectsTimeCodetypeautomatically 

• TimeCodelevelsetautomatically

• Softwarerunsasaserviceunder

WindowsXP/7/Server2003and2008

Time Code Reade

Model # TCR1000
