Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



Ourmasterclockreference(MCR)isaPCIcardthat

providesverystableaccuratetimeanddateinformation

foraWindowsPC.ThecardusesaRealTimeClock(RTC)

chipandoscillatorwithtemperature compensationto

stabilizethePCclock.TheMCRmaintainsPCaccuracyto

165mSecperday,

or1minuteperyear.Theonboard

clockrunsfromabackupbatteryintheabsenceofpower

fromthePC.



FEATURES



• AccurateclockreferenceforPCs

• Providemillisecondaccuracytoapplicationsand

automationsystems

• Suppliedwithsoftwaretoallowusertosetthecard

whichthensetsthePCclock

• Abilitytoupdatefromstableexternaltimesource

usingDLLsandAPIsforcustomprogramming;

includessamplesourcecode

• RealTimeClockchip&oscillatorwithtemperature

compensation

• DriversandAPIsincludedforWindows

98/ME/NT/2000andXP

• Stabilityof±165msperday

SPECIFICATIONS



SoftwareIncluded

• Devicedriver

• DLLwithdocumentedAPI

• MCRSETutilitypermitsdirectlyviewing,

setting,andcomparingtime

• MCRSYNCserviceautomaticallykeepsPC

clocksynchronized



MCRPCIConfiguration

• Automaticportandinterruptselection

(plugandplaycompatible)



PC Card

MCR-PCI Real Time Clock Card

OperatingTemperatures

• Temperature:0to+60°C



Physical

• One‐thirdslotPCIcard

• Longlifebatteryonboardrunsclock

whenPCispoweredoff

• Accurateto±1minute/yearat

0°C‐40°C



DataAvailable

• Timeinhours,minutes,seconds,

millisecondswithprecisiontimestam

available
